îòáã Intel Ultra 5 235 5.0GHz 24 MB LGA1851 BOX
-
î÷è: ULTRA-5-235-BOX
-
àçøéåú: 36 çåãùéí
-
÷éùåø ìàúø éöøï: Intel
-
îñôø úùìåîéí: 5
îçéø ¤ 1,350
çæøå àìé á÷ùø ìîåöø æä
îãåò ì÷ðåú àöìðå?
îúçééáéí ìùéøåú
àîéï åî÷öåòé
îùìåçéí ìëì
çì÷é äàøõ
îçéøéí ììà
úçøåú
ðéñéåï ùì
20 ùðä
îãåò ì÷ðåú àöìðå?
îúçééáéí ìùéøåú
àîéï åî÷öåòé
îùìåçéí ìëì
çì÷é äàøõ
îçéøéí ììà
úçøåú
ðéñéåï ùì
20 ùðä
ùéøåú ì÷åçåú î÷öåòé, îçéøéí àèø÷èéáééí åæîðé àñô÷ä îäéøéí!
- àçøéåú: 36çåãùéí
- æîï àñô÷ä: òã7éîé òñ÷éí
Product Collection
Intel® Core™ Ultra Processors (Series 2)
Code Name
Products formerly Arrow Lake
Vertical Segment
Desktop
Processor Number Intel® processor numbers for the Data Center
235
Overall Peak TOPS (Int8)
27
CPU Specifications
Total Cores
14
# of Performance-cores
6
# of Efficient-cores
8
Total Threads
14
Max Turbo Frequency
For more details regarding the dynamic power and frequency operating range, refer to Performance Proxy Frequently Asked Questions (FAQs) for Intel® Processors." data-search-title="Find products with Max Turbo Frequency" data-search-href="" data-search-icon="true" data-keyboard="true" aria-label="Max Turbo Frequency">
For more details regarding the dynamic power and frequency operating range, refer to Performance Proxy Frequently Asked Questions (FAQs) for Intel® Processors." data-search-title="Find products with Max Turbo Frequency" data-search-href="" data-search-icon="true" data-keyboard="true" aria-label="Max Turbo Frequency">
5 GHz
Performance-core Max Turbo Frequency
For more details regarding the dynamic power and frequency operating range, refer to Performance Proxy Frequently Asked Questions (FAQs) for Intel® Processors." data-search-title="Find products with Performance-core Max Turbo Frequency" data-search-href="" data-search-icon="true" data-keyboard="true" aria-label="Performance-core Max Turbo Frequency">
For more details regarding the dynamic power and frequency operating range, refer to Performance Proxy Frequently Asked Questions (FAQs) for Intel® Processors." data-search-title="Find products with Performance-core Max Turbo Frequency" data-search-href="" data-search-icon="true" data-keyboard="true" aria-label="Performance-core Max Turbo Frequency">
5 GHz
Efficient-core Max Turbo Frequency
For more details regarding the dynamic power and frequency operating range, refer to Performance Proxy Frequently Asked Questions (FAQs) for Intel® Processors." data-search-title="Find products with Efficient-core Max Turbo Frequency" data-search-href="" data-search-icon="true" data-keyboard="true" aria-label="Efficient-core Max Turbo Frequency">
For more details regarding the dynamic power and frequency operating range, refer to Performance Proxy Frequently Asked Questions (FAQs) for Intel® Processors." data-search-title="Find products with Efficient-core Max Turbo Frequency" data-search-href="" data-search-icon="true" data-keyboard="true" aria-label="Efficient-core Max Turbo Frequency">
4.4 GHz
Performance-core Base Frequency
3.4 GHz
Efficient-core Base Frequency
2.9 GHz
Cache
24 MB Intel® Smart Cache
Total L2 Cache
26 MB
Processor Base Power
65 W
Maximum Turbo Power
121 W
Intel® Deep Learning Boost (Intel® DL Boost) on CPU
Yes
AI Software Frameworks Supported by CPU
OpenVINO™, WindowsML, DirectML, ONNX RT, WebNN
CPU Lithography
TSMC N3B
Supplemental Information
Marketing Status
Launched
Launch Date
Q1'25
Embedded Options Available
No
Use Conditions For SKU specific use condition information, see PRQ report.
For current use condition information, see Intel UC (CNDA site)*." data-search-title="Find products with Use Conditions" data-search-href="" data-search-icon="true" data-keyboard="true" aria-label="Use Conditions">
For current use condition information, see Intel UC (CNDA site)*." data-search-title="Find products with Use Conditions" data-search-href="" data-search-icon="true" data-keyboard="true" aria-label="Use Conditions">
PC/Client/Tablet, Workstation
Datasheet
View now
Memory Specifications
Max Memory Size (dependent on memory type)
192 GB
Memory Types
Up to DDR5 6400 MT/s
Max # of Memory Channels
2
ECC Memory Supported ‡
Yes
GPU Specifications
GPU Name‡
Intel® Graphics
Graphics Base Frequency Performance Proxy Frequently Asked Questions (FAQs) for Intel® Processors
300 MHz
Graphics Max Dynamic Frequency
For more details regarding the dynamic power and frequency operating range, refer to Performance Proxy Frequently Asked Questions (FAQs) for Intel® Processors." data-search-title="Find products with Graphics Max Dynamic Frequency" data-search-href="" data-search-icon="true" data-keyboard="true" aria-label="Graphics Max Dynamic Frequency">
For more details regarding the dynamic power and frequency operating range, refer to Performance Proxy Frequently Asked Questions (FAQs) for Intel® Processors." data-search-title="Find products with Graphics Max Dynamic Frequency" data-search-href="" data-search-icon="true" data-keyboard="true" aria-label="Graphics Max Dynamic Frequency">
2 GHz
GPU Peak TOPS (Int8)
6
Graphics Output
DP2.1 UHBR20, HDM2.1 FRL 12GHz, eDP1.4b
Xe-cores
3
Max Resolution (HDMI)‡
4K @ 60Hz (HDMI 2.1 TMDS) 8K @ 60Hz (HDMI2.1 FRL)
Max Resolution (DP)‡
8K @ 60Hz
Max Resolution (eDP - Integrated Flat Panel)‡
4K @ 60Hz
DirectX* Support
12
OpenGL* Support
4.5
OpenCL* Support
3
Intel® Quick Sync Video
Yes
# of Displays Supported ‡
4
Device ID
0x7D67
Intel® Deep Learning Boost (Intel® DL Boost) on GPU
Yes
NPU Specifications
NPU Name‡
Intel® AI Boost
NPU Peak TOPS (Int8)
13
Sparsity Support
Yes
Windows Studio Effects Support
Yes
AI Software Frameworks Supported by NPU
OpenVINO™, WindowsML, DirectML, ONNX RT, WebNN
Expansion Options
Direct Media Interface (DMI) Revision
4
Max # of DMI Lanes
8
Intel® Thunderbolt™ 4
Yes
Scalability
1S Only
PCI Express Revision
5.0 and 4.0
PCI Express Configurations ‡
Up to 1x16+2x4, 2x8+2x4,
1x8+4x4
1x8+4x4
Max # of PCI Express Lanes
24
Package Specifications
Sockets Supported
FCLGA1851
Thermal Solution Specification
PCG 2022C
Max Operating Temperature
105 °C
Advanced Technologies
Intel® Volume Management Device (VMD)
Yes
Intel® Gaussian & Neural Accelerator
3.5
Intel® Thread Director
Yes
Intel® Speed Shift Technology
Yes
Intel® Turbo Boost Technology ‡
2.0
Intel® 64 ‡
Yes
Instruction Set
64-bit
Instruction Set Extensions
Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2
Idle States
Yes
Enhanced Intel SpeedStep® Technology
Yes
Thermal Monitoring Technologies
Yes
Security & Reliability
Intel vPro® Eligibility ‡
Intel vPro® Enterprise, Intel vPro® Platform
Intel® Hardware Shield Eligibility ‡
Yes
Intel® Threat Detection Technology (TDT)
Yes
Intel® Active Management Technology (AMT) ‡
Yes
Intel® Standard Manageability (ISM) ‡
Yes
Intel® Remote Platform Erase (RPE) ‡
Yes
Intel® One-Click Recovery ‡
Yes
Intel® Control-Flow Enforcement Technology
Yes
Intel® Total Memory Encryption - Multi Key
Yes
Intel® AES New Instructions
Yes
Secure Key
Yes
Intel® Trusted Execution Technology ‡
Yes
Execute Disable Bit ‡
Yes
Intel® OS Guard
Yes
Intel® Boot Guard
Yes
Mode-based Execute Control (MBEC)
Yes
Intel® Stable IT Platform Program (SIPP) Learn more about Intel® SIPP
Yes
Intel® Virtualization Technology with Redirect Protection (VT-rp) ‡
Yes
Intel® Virtualization Technology (VT-x) ‡
Yes
Intel® Virtualization Technology for Directed I/O (VT-d) ‡
Yes
Intel® VT-x with Extended Page Tables (EPT) ‡
Yes
| ùãøåâéí | |
|---|---|
| Socket: | intel 1851 |
| ñåâ îòáã: | Intel Ultra 5 15th Gen |
| ìéáä âøôéú: | ëåìì ìéáä âøôéú |
| îñôø ìéáåú: | 24 |
| æéëøåï: | 24MB |
| àøéæä: | BOX ìà ëåìì îàååø |
